Motorola G24 Guide User Manual

Chapter 3: AT Commands Reference
December 31, 2007 AT Commands Reference Manual 3-217
+MIOD, Motorola I/O Define
This command defines the G24 8 GPIO pins configuration. The feature is flex enabled or
disabled.
This command is a basic command.
The feature is active by default, however, changing the FLEX can eliminate it.
Note: When using the GPIO lines feature, lines should not be connected directly to ground, a
resistor must be used. This is applicable when changing an I/O from input to output.
Command
Type Syntax Response/Action Remarks
Set
AT+MIOD=<Pin
selection>,<Mode>
[,<Data vector>]
OK
or:
+CME ERROR: <err>
The set command defines the behavior
mode of each selected IO pin.
The G24 saves the new setting in flex.
The selected pins are affected. Validity
check of all parameters will be done
and appropriate standard error will be
issued.
In case of legal parameters the new
configuration is set. If <Data vector>
doesn't supply and new <Mode> is
output a line will care physical high
signal. In case <Data vector> is supply
and includes values of input pins, those
values will be ignored. In case
<Mode> is input and <Data vector> is
supply, an error will be issued
"Operation not allowed". No action
will be done.
Read
+ MIOD? +MIOD: <Mode vector>
OK
The read command returns the current
behavior mode of the 8 GPIO pins.
Test
+ MIOD=? +MIOD: (list of
supported <Pin
selection>s),(list of
supported
<Mode>s),(list of
supported <Data
vector>s)
OK
or:
+CME ERROR: <err>
The test command returns the possible
ranges of <Pin selection>s, <Mode>s
and <Data vector>s.
