Network
3-180 AT Commands Reference Manual December 31, 2007
Example
AT+MCELL = 0,1
+MCELL: Serving Idle/PI
BC0077s* 50-071B
BC0077 Gpid39051
h04p00+33+33-104
t00r00a04t20t09d
a1mcc425mnc01 C
lac09800rac00001
OK
AT+MCELL = 0,9
+MCELL: Adjacent Cell 4
BC0077s* 50-071B
<screen_title> The requested screen title is written on the first line of each screen. See Table 3-108.
<screen_info> The requested screen information. See screens description, Table 3-109 through
Table 3-120.
Table 3-108: Title to Screen Mapping
<screen title> Description <screen num>
Serving Idle/PI Idle/Packet Idle mode; Serving Cell Information screen. 1
Serving CS/TBF Circuit Switched mode; Serving Cell Information screen. 2
Serving Misc Idle/Packet Idle mode; Miscellaneous Information
screen.
3
Uplink Transfer Dedicated/TBF modes; Uplink Data Transfer screen. 4
Dnlink Transfer Dedicated/TBF modes; Downlink Data Transfer screen. 5
Adjacent Cell x Neighbor Cell Information screen.
x - index cell.
6-11
Neighbors Neighbor Cells Summary screen. 12
Reselection Re-selection screen. 13
Hopping Info Dedicated/TBF modes; Hopping Information screen. 14
PDP Context x PDP Context Information screen
x - index cell.
15-18
Paging Params Idle/Packet Idle mode; Serving Cell Paging parameters. 19
SysInfos Idle/Packet Idle mode; Optional SYSINFO. 20
Table 3-107: +MCELL Parameters (Cont.)
<Parameter> Description
