Chapter 3: AT Commands Reference
December 31, 2007 AT Commands Reference Manual 3-373
The following table shows the +MTKP Set parameters.
Note: If the SIM asks for yes/no answer then respond with 0 or 1.
Example
+ MTKP: 1,0,Hello //Display text cmd was sent from SIM (number 1), with normal
priority (number 0), and the text is "hello"
Table 3-252: +MTKP Set Command Parameters
<Parameter> Description
<CmdType> 2 Response for a "Get Inkey"
3 Response for a "Get Input"
Values when CmdType=2 (Get Inkey)
<Result> 0 Session ended by user.
1 Response given by the user.
2 Help information required by user.
<Data> Key pressed by the user.
Values when CmdType=3 (Get Input)
<Result> 0 Session ended by user.
1 Response given by the user.
2 Help information required by user.
<Data> String of characters entered by the user.
Values when CmdType=16 (Set Up Event List)
<Result> 5 User activity event.
6 Idle Screen Available event.
8 Language Selection event.
9 Browser Termination event.
<Data> None User activity event
None Idle Screen Available event
0 Browser Termination event (user terminated)
1 Browser Termination event (error terminated)
4 String coded as follows:
Byte(s) Description Length
1 Language tag 1
2 Length=’02’ 1
3-4 Language 2
Values when CmdType=24 (DTMF service)
<Result> 0 disable DTMF service.
1 enable DTMF, short tones.
2 enable DTMF, long tones.
<Data> None
