TDSC 1/2/3 U0
You can use this parameter to set the desired value which is to be used
when the measured active power is 0.
1. Go to Settings > Parameter > Control > TDSC U0.
2. Enter desired value at active power 0.
3. Press the Accept button to save the modified parameter.
TDSC 1/2/3 Pmax/Pmin
You can use these parameters to set the maximum and minimum active
power value at which the maximum and minimum active power-dependent
desired value is to be used for regulation.
1. Go to Settings > Parameters > Control > TDSC Pmax/Pmin.
2. Enter active power for maximum/minimum desired value.
3. Press the Accept button to save the modified parameter.
8.12.1.8 Desired value setting via BCD
With the desired value setting via BCD, you can variably adjust the desired
value for the automatic voltage regulation via digital inputs by means of BCD
coding.
Depending on variant, desired value setting via BCD is always active or you
can activate it by creating a signal at the BCD desired value input.
The following outputs are available to you as an option:
▪ Desired value setting faulty: The device issues a signal if the BCD code
for the desired value setting is invalid.
▪ Desired value active: The device issues a signal if desired value setting
via BCD is active.
The permissible setting range is 49...140V. The specified value is written to
the parameter desired value 1. If the BCD coding is invalid or desired value
setting via BCD is deactivated, the device uses the value set in parameter
desired value 1.
Desired
value
BCD input
100 80 40 20 10 8 4 2 1
49 V 0 0 1 0 0 1 0 0 1
50 V 0 0 1 0 1 0 0 0 0
51 V 0 0 1 0 1 0 0 0 1
52 V 0 0 1 0 1 0 0 1 0
53 V 0 0 1 0 1 0 0 1 1
54 V 0 0 1 0 1 0 1 0 0
55 V 0 0 1 0 1 0 1 0 1
56 V 0 0 1 0 1 0 1 1 0
