8 Operation
Maschinenfabrik Reinhausen GmbH 2020 1493587317/21 EN TAPCON
®
Desired
value
BCD input
100 80 40 20 10 8 4 2 1
57 V 0 0 1 0 1 0 1 1 1
58 V 0 0 1 0 1 1 0 0 0
59 V 0 0 1 0 1 1 0 0 1
60 V 0 0 1 1 0 0 0 0 0
61 V 0 0 1 1 0 0 0 0 1
62 V 0 0 1 1 0 0 0 1 0
63 V 0 0 1 1 0 0 0 1 1
64 V 0 0 1 1 0 0 1 0 0
65 V 0 0 1 1 0 0 1 0 1
66 V 0 0 1 1 0 0 1 1 0
67 V 0 0 1 1 0 0 1 1 1
68 V 0 0 1 1 0 1 0 0 0
69 V 0 0 1 1 0 1 0 0 1
70 V 0 0 1 1 1 0 0 0 0
71 V 0 0 1 1 1 0 0 0 1
72 V 0 0 1 1 1 0 0 1 0
73 V 0 0 1 1 1 0 0 1 1
74 V 0 0 1 1 1 0 1 0 0
75 V 0 0 1 1 1 0 1 0 1
76 V 0 0 1 1 1 0 1 1 0
77 V 0 0 1 1 1 0 1 1 1
78 V 0 0 1 1 1 1 0 0 0
79 V 0 0 1 1 1 1 0 0 1
80 V 0 1 0 0 0 0 0 0 0
81 V 0 1 0 0 0 0 0 0 1
82 V 0 1 0 0 0 0 0 1 0
83 V 0 1 0 0 0 0 0 1 1
84 V 0 1 0 0 0 0 1 0 0
85 V 0 1 0 0 0 0 1 0 1
86 V 0 1 0 0 0 0 1 1 0
87 V 0 1 0 0 0 0 1 1 1
88 V 0 1 0 0 0 1 0 0 0
89 V 0 1 0 0 0 1 0 0 1
90 V 0 1 0 0 1 0 0 0 0
91 V 0 1 0 0 1 0 0 0 1
