4 Product description
Maschinenfabrik Reinhausen GmbH 2020 313587317/21 EN TAPCON
®
Display showing measured value trend
Figure9: Measured value trend
1 Desired value 2 Upper limit of bandwidth
3 Trend of measured voltage 4 Delay time T1/T2
5 Trend of corrected voltage (correc-
tion due to compensation or paral-
lel operation)
6 Lower limit of bandwidth
