User Manual for the NETGEAR 7300 Series Layer 3 Managed Switch Software
CLI Commands: Differentiated Services 10-11
202-10009-01_060204
To specify the match condition as a single keyword notation, the value for <portkey> is one of the
supported port name keywords (listed below).
The currently supported <
portkey> values are: domain, echo, ftp, ftpdata, http, smtp, snmp, telnet, tftp,
www
. Each of these translates into its equivalent port number, which is used as both the start and
end of a port range.
To specify the match condition as a numeric value, one layer 4 port number is required. The port
number is an integer from 0 to 65535.
To specify the match condition as a range, two layer 4 port numbers are required and together they
specify a contiguous port range. Each port number is an integer from 0 to 65535, but with the
added requirement that the second number be equal to or greater than the first. The optional [
not]
parameter has the effect of negating this match condition for the class (i.e., match all source layer 4
ports except for those within the range specified here).
The optional [
not] parameter has the effect of negating this match condition for the class (i.e.,
match all source layer 4 port numbers except for the one specified here).
Default
None
Format match [not] srcl4port {<portkey> | <0-65535> [<0-
65535>]}
Mode Class-Map Config
match vlan
This command adds to the specified class definition a match condition based on the value of the
layer 2 VLAN Identifier field of a packet. The VLAN ID is an integer from 1 to 4094. The
optional [
not] parameter has the effect of negating this match condition for the class (i.e., match all
VLAN Identifier values except for what is specified here).
Default
None
Format match [not] vlan <1-4094>
Mode Class-Map Config
Policy Commands
The 'policy' command set is used in DiffServ to define:
