NETGEAR 7300 Series User Manual

User Manual for the NETGEAR 7300 Series Layer 3 Managed Switch Software
6-6 Quick Start up
202-10009-01_060204
Quick Start up Downloading from Out-of-Band PC to Switch
(Only XMODEM)
Quick Start up Downloading from TFTP Server
Before starting a TFTP server download, the operator must complete the Quick Start up for the IP
Address.
Table 6-6. Quick Start up Downloading from Out-of-Band PC to Switch (Only XMODEM)
Command Details
copy <url> {nvram:startup-config |
system:image}
Sets the download datatype to be an image or
config file.
The URL must be specified as:
xmodem:filepath/fileName
For example:
If the user is using HyperTerminal, the user
must specify which file is to be sent to the
switch.
The Switch will restart automatically once the
code has been downloaded.
Table 6-7. Quick Start up Downloading from TFTP Server
Command Details
copy <url> {nvram:startup-config |
system:image}
Sets the download datatype to be an image
or config file.
The URL must be specified as:
tftp://ipAddr/filepath/fileName.
The nvram:startup-config option downloads
the config file using tftp and system:image
option downloads the code file.

NETGEAR 7300 Series Specifications

General

Model	NETGEAR 7300 Series
Form Factor	Rack-mountable
VLAN Support	Yes
Jumbo Frame Support	9KB
Management	Web-based, CLI
Layer	Layer 2/3
