13-4 FSM7326P Power Over Ethernet Commands
202-10009-01_060204
The following fields are displayed for each port. If a port does not have link, or is not enabled for
PoE, the following fields display a value of "N/A".
Class
The Class field reports the class of the powered device according to IEEE802.3af definition.
Output
The Output field reports the power supplied to the powered device (in watts).
Limit
The LIMIT field is the preset limit defined by the "config poe port limit" command. This value is
stated in watts.
Status
The Status field reports the state of power supplied to the associated port. Possible values are:
• Disabled — the POE function is disabled on this port
• Searching — the port is detecting POE device
• Delivering Power — the port is providing power to POE device
• Fault — the POE device is not IEEE compliance, no power is provided
• Test — the port is in testing state
• Other Fault — the port has experience problems other than compliance issue
When a port begins to deliver power, there will be a trap indicating so. When a port stops
delivering power, there will be a trap indicating so.
Table 13-1. Class of the Powered Device
Class Usage Max Power
0 Default
0.44-12.95
1 Optional
0.44-3.84
2 Optional
3.84-6.49
3 Optional
6.49-12.95
4 Not Allowed
Reserved
