User Manual for the NETGEAR 7300 Series Layer 3 Managed Switch Software
10-14 CLI Commands: Differentiated Services
202-10009-01_060204
Note: The CLI mode is changed to Policy-Class-Map Config when this command is successfully
executed.
Format
class <classname>
Mode Policy-Map Config
no class
This command deletes the instance of a particular class and its defined treatment from the
specified policy. <
classname> is the names of an existing DiffServ class. Note that this command
removes the reference to the class definition for the specified policy.
Format
no class <classname>
Mode Policy-Map Config
mark ip-dscp
This command marks all packets for the associated traffic stream with the specified IP DSCP
value.
The <dscpval> value is specified as either an integer from 0 to 63, or symbolically through one of
the following keywords:
af11, af12, af13, af21, af22, af23, af31, af32, af33, af41,
af42, af43, be, cs0, cs1, cs2, cs3, cs4, cs5, cs6, cs7, ef.
Format mark ip-dscp <dscpval>
Mode Policy-Class-Map Config
Policy Type In
Incompatibilities Mark IP Precedence, Police (all forms)
mark ip-precedence
This command marks all packets for the associated traffic stream with the specified IP Precedence
value. The IP Precedence value is an integer from 0 to 7.
Format
mark ip-precedence <0-7>
Mode Policy-Class-Map Config
Policy Type In
Incompatibilities Mark IP DSCP, Police (all forms)
