NETGEAR 7300 Series User Manual

User Manual for the NETGEAR 7300 Series Layer 3 Managed Switch Software
B-8 Cabling Guidelines
202-10009-01_060204
Table 13-2. 100/1000 Mbps RJ-45 Plug and RJ-45 Connector Pin Assignments
Conclusion
For optimum performance of your 1000BASE-T product, it is important to fully qualify your cable
installation and ensure it meets or exceeds ANSI/EIA/TIA-568-A:1995 or ISO/IEC 11801:1995
Category 5 specifications. Install Category 5e cable where possible, including patch panel cables.
Minimize transition points, jacket removal, and untwist lengths. Bundling of cables must be
properly installed to meet the requirements in ANSI/EIA/TIA-568A-3.
PIN CHANNEL DESCRIPTION
1
2
A Rx/Tx Data +
Rx/Tx Data
3
6
B Rx/Tx Data +
Rx/Tx Data
4
5
C Rx/Tx Data +
Rx/Tx Data
7
8
D Rx/Tx Data +
Rx/Tx Data

NETGEAR 7300 Series Specifications

General

Model	NETGEAR 7300 Series
Form Factor	Rack-mountable
VLAN Support	Yes
Jumbo Frame Support	9KB
Management	Web-based, CLI
Layer	Layer 2/3
