User Manual for the NETGEAR 7300 Series Layer 3 Managed Switch Software
CLI Commands: Differentiated Services 10-1
202-10009-01_060204
Chapter 10
CLI Commands: Differentiated Services
This chapter contains the CLI commands used for the QOS Differentiated Services (DiffServ)
package.
The user configures DiffServ in several stages by specifying:
1. Class
• creating and deleting classes
• defining match criteria for a class.
Note: The only way to remove an individual match criterion from an existing class definition is to
delete the class and re-create it.
2. Policy
• creating and deleting policies
• associating classes with a policy
• defining policy statements for a policy/class combination
3. Service
• adding and removing a policy to/from a directional (i.e., inbound, outbound) interface
Packets are filtered and processed based on defined criteria. The filtering criteria is defined by a
class. The processing is defined by a policy's attributes. Policy attributes may be defined on a per-
class instance basis, and it is these attributes that are applied when a match occurs.
Packet processing begins by testing the match criteria for a packet. A policy is applied to a packet
when a class match within that policy is found.
