User Manual for the NETGEAR 7300 Series Layer 3 Managed Switch Software
7-6 Mode-based CLI
202-10009-01_060204
the router interface configuration commands. The command
prompt at this level is:
Command Prompt: $(Interface <slot/port>)#
The resulting prompt for the interface configuration command
entered in the Global Configuration mode is shown below:
$(Config)# interface 2/1
$(Interface 2/1)#
Line Config Mode This mode allows the operator to configure the console interface.
The operator may configure the interface from the directly con-
nected console or the virtual terminal used with Telnet. The com-
mand prompt at this level is:
Command Prompt: $(Line)#
Policy Map Mode Use the policy-map command to access the QoS policy map con-
figuration mode to configure the QoS policy map.
$(Config)# policy-map
Command Prompt: $(Config policy-map)#
Policy Class Mode Use the "class" command to access the QoS policy- classmap
mode to configure the QoS policy map.
$(Config-policy-map)# class
Command Prompt: $(Config - policy-classmap)#
Class Map Mode This mode consists of class creation/deletion and matching com-
mands. The class match commands specify layer 2, layer 3 and
general match criteria. Use the class-map commands to access the
QoS class map configuration mode to configure QoS class maps.
$(Config)# class map
Command Prompt: $(Config - class)#
Router Config OSPF Mode In this mode, the operator is allowed to access the router OSPF
configuration commands. The command prompt at this level is:
$(Config)# router ospf
Command Prompt: $(Config-router)#
Router Config RIP Mode In this mode, the operator is allowed to access the router RIP con-
figuration commands. The command prompt at this level is:
$(Config)# router rip
Command Prompt: $(Config-router)#
DHCP Pool Configuration Mode Use the ip dhcp pool <pool-name> command to access the
DHCP Pool Config Mode.
