The APA-Module LU 6.2 Connection APA-Module Components
28 A29247-X2-X-8-7670
deleted This connection could not be found in the SNAP-IX
database, e.g. it was deleted, renamed or it was cre-
ated by snafile2tcp.
Note: Since the state transitions occur within a very short space of
time, users will generally only see the two underlined entries: closed
and active.
Display Name The name is to Identify the LU6.2 Connection
Server Name The name of the PRISMA Server where the Connection is configured
ID The PRISMAproduction Number of the Connection
Local LU The name of the local LU (logical unit) via which the connection with the
MVS system was established.
Partner LU The name of the partner LU of the MVS-System which is connected to
PRISMAproduction.
Pages Specifies the total number of pages sent via the MVS-SIEPRIS commu-
nications channel. Note that this number does not necessarily corre-
spond with the current print page number.
MVS Job Name The name of the print job currently being transferred from the MVS sys-
tem.
Bytes This attribute indicates the number of bytes transferred via the MVS-
SIEPRIS channel (not including resources).
MVS Form This attribute states which FORMDEF is used in the print job currently
being transferred.
MVS Job Number This is the MVS identifier for the print job currently being transferred.
MVS Out Queue The name of the MVS job class from which the current print job was tak-
en.
Destination The name of the Destination Printer, the Job should be printed on
