Oki MC860 Maintenance Manual

43967002TH Rev.1
104 /
Oki Data CONFIDENTIAL
3. Installation
The shaded portion shows the default setup value when shipped from the factory.
Item Contents
Speed Dial
* If
communication
reservation is
being made,
abbr. dial cannot
be changed or
deleted.
Delete snd Sort Delete address and roll up in order.
Insert Input the address.
Group Name Set name of group.
Maximum 16 characters with half-sized
character, or 8 characters with full size can
be registered.
Speed Dial Select Speed Dial.
500 address numbers can be registered for
a group.
When [Paper Setup] is pressed
The shaded portion shows the default setup value when shipped from the factory.
Item Contents
Tray 1 Paper Size
Cassette size
Custom
Select a paper size.
Custom Width 105 mm
210 mm
297 mm
It can be set only when Custom is selected as
paper size.
(Display in units of mm or display in units of inch
can be switched by changing the unit of display on
the system setup).
4.1 inch
8.3 inch
11.7 inch
Length 148 mm
297 mm
431 mm
It can be set only when Custom is selected as
paper size.
(Display in units of mm or display in units of inch
can be switched by changing the unit of display on
the system setup).
5.8 inch
11.0 inch
17.0 inch
The shaded portion shows the default setup value when shipped from the factory.
Item Contents
Tray 1 Media Type Plain
Letter Head
Bond
Recycled
Rough
Glossy
Select type of paper.
Media Weight Light
Medium
Heavy
Select weight of paper.
Ultra heavy paper cannot be set.
Tray 2 Paper Size Cassette size
Custom
Select a paper size.
Custom
Size
Width 148 mm
210 mm
297 mm
It can be set only when Custom is selected as
paper size.
(Display in units of mm or display in units of inch
can be switched by changing the unit of display on
the system setup).
5.8 inch
11.0 inch
17.0 inch

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
