5. Maintenance Menu
5.8.4 Pulse Make Ratio
Value Default Display condition
Default for countries
33%
39%
40%
For the value that is used
when the setting value is
“Country-wise initial value”,
refer to item 5.8.9.
None
Sets the make ratio of DP (10 pps) during call.
5.8.5 MF(Tome) Duration
5.8.5.1 ON period
Value Default Display condition
0
1 ms
255 ms
0 (Default for countries)
For the value that is used
when the setting value is 0,
refer to item 5.8.9.
None
Sets the ON period of MF(Tone) Duration send.
When the setting value is “0”, the MC860 runs at the initial value of each country.
When the set value is except "0", the set value operates at 1 to 255m second.
5.8.5.2 OFF period
Value Default Display condition
0
1 ms
255 ms
0(Default for countries)
For the value that is used
when the setting value is 0,
refer to item 5.8.9.
None
Sets the OFF period of MF(Tone) Duration send.
When the setting value is “0”, the MFP runs at the initial value of each country.
When the set value is except "0", the set value operates at 1 to 255m second.
5.8.6 Colling Timer
Value Default Display condition
0
1 second
255 seconds
0 (Default for countries)
For the value that is used
when the setting value is 0,
refer to item 5.8.9.
None
Sets the Colling Timer. When the setting value is “0”, the MC860 runs at the initial value of
each country. When any value other than “0” is set, the Colling Timer can be selected in the
range of 1 to 255 mm.
5.8.7 Attenuator
Value Default Display condition
0 dB
-15 dB
Refer to item 5.8.9. None
Sets the Attenuator. It can be set in units of 1 dB.
When the “Country code” is set to “Japan”, it can be set in the range of 8 to 15 dB.
5.8.8 MF Attenuator
Value Default Display condition
0 dB
-15 dB
Refer to item 5.8.9. None
Sets the MF Attenuator.
It can be set in units of 1 dB.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
