Oki MC860 Maintenance Manual

Oki Data CONFIDENTIAL
43967002TH Rev. 1
350 /
7. Troubleshooting
7.5.3.(3) All white page print (Refer to Fig. 7-2 C)
(3-1) All white page print on paper
Check item Check work
Action to be taken at NG
(3-1-1) Toner condition
Residual amount of
toner
Check that sufficient amount toner remains
inside the toner cartridge.
Replace the toner
cartridge
(3-1-2) Exposure condition
LED head Check that the LED head is located in the
good position where the LED head f
aces
against drum in the specified position.
Check if there exists any obstacle that
prevents irradiation on the irradiating
surface of LED.
LED head
installation condition
should be corrected.
LED head
connecting condition
Check that the LED head is normally
connected.
Replace the LED
head
Drum shaft Check that the drum shaft is contacting
with the right and left side plates normally.
Replace the ID unit.
If any attempt of
using new ID unit
as a trial is going to
be made, be sure
to use the System
Maintenance Menu
FUSE KEEP MODE.
(3-1-3)
High voltage ter
minal
ID unit terminal Confirm that the ID unit high voltage
terminal keeps contacting with the high
voltage terminal by visual check.
(Refer to Fig. 7-3.)
ID unit replacement
or high voltage
terminal repair If
any attempt of using
new ID unit as a
trial is going to be
made, be sure to
use the System
Maintenance Menu
FUSE KEEP MODE.
7.5.3.(4) Vertical line is printed
(4-1) Thin vertical line (with color) (Refer to Fig. 7-2 D)
Check item Check work
Action to be taken at NG
(4-1-1) ID unit condition
ID unit filming Has the MFP made printing without toner? Replace the toner
cartridge with new
one. If it does not
correct the trouble,
replace the ID unit.
If any attempt of
using new ID unit
as a trial is going to
be made, be sure
to use the System
Maintenance Menu
FUSE KEEP MODE.
(4-2) Thin vertical line (with color)(Refer to Fig. 7-2 F)
Check item Check work
Action to be taken at NG
(4-2-1) LED head condition
LED head Is there any foreign material attached to
the irradiating surface of the LED head?
Remove the foreign
material.
(4-2-2) Paper r
unning condition
Paper running path Check there is no blur in the paper running
path, that cause to scrape the non-fused
toner.
Remove the blur.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
