4. Part Replacement
4.2.3.17 Gear box/Regist/Hopping roller Assy/Solenoid
(1) Remove the regist roller Assy. (Refer to chapter 4.2.17.)
(2) Disconnect the cable
from the solenoid . Remove the screw (silver) and the
solenoid
.
(3) Remove the spring
.
