Oki MC860 Maintenance Manual

43967002TH Rev.1
22 /
Oki Data CONFIDENTIAL
1. Configuration
Item
Compatibility ITU-T Super G3
Compression system MH/MR/MMR JBIG
Communication speed 33600 bps (automatic fallback)
Document size A3 (SEF), B4 (SEF), A4 (SEF/LEF), A5 (SEF/LEF),.B5
(SEF/LEF)
Effective scanning size Within 1.5 mm from top/bottom/right/left of document
ends
Transmission speed Approx. 2 seconds
Number of
alternate
receptions
Send Approx. 95 sheets
Receive Approx. 250 sheets
Scanning line
density
Horizontal
scanning
8 dots/mm
Vertical scanning 3.85 lines/mm (Standard)
7.7 lines/mm (Fine)
15.4 lines/mm (Photo)
Density adjustment Lightest/Lighter/Normal/Darker/Darkest
Telephone network PSTN (Public Switched Telephone Network)
Line connection system Communication connector (RJ-11)
Network control function Automatic and manual
Selection signal system PB/DP (10/20 PPS) switched by software
DC resistance Maximum approx. 240 ohms
Maximum number of connectable
lines
1
Send/Receive memory 16MB
Resolution Std: 200 x 100dpi, Fine: 200 x 200dpi,
Photo: 200 x 200dpi, ExFine: 200 x 400dpi
Fax section specifications
Item
Resolution 600dpi X 600dpi, 300dpi X 300dpi
Document size Flat bed ODA
Tabloid(SEF), Legal(SEF), Letter(SEF/LEF),
HalfLetter(LEF)
OEL
A3(SEF),B4(SEF),A4(SEF/LEF),A5(SEF/LEF),
B5(SEF/LEF)
ADF ODA
Tabloid(SEF), Legal(SEF), Letter(SEF/LEF),
HalfLetter(LEF)
OEL
A3(SEF),B4(SEF),A4(SEF/LEF),A5(SEF/LEF),
B5(SEF/LEF)
Effective scanning size Within 4.23mm from top/bottom/right/left of document
ends
Copy speed Color: 26 pages/minute (300 dpi x 300 dpi)
9 pages/minutes (600 dpi x 600 dpi)
Monochrome: 34(A4), 33(Letter) pages/minute (300 dpi
x 300 dpi)
9 to 20 pages/minutes (600 dpi x 600 dpi)
First print time Flat bed Color: 14.5 sec, Mono: 13sec
ADF Color: 14.5 sec, Mono: 13 sec
COPY mode Text, Text&Photo, Photo, Extra Fine
Copy by specifying number of
copies
Maximum 999 copies
Copy density Removal for
Background
&Show-Through
(sTHR)
Auto, OFF, 1 – 5, sTHR
Density -3 (thin) to 0 to +3 (thick)
Contrast -3 (low) to 0 to +3 (high)
Saturation -3 (low) to 0 to +3 (high)
Hue -3 (red) to 0 to +3 (green)
RGB RGB each color, -3 (low) to 0 to +3 (high)
Copy function

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
