Oki MC860 Maintenance Manual

43967002TH Rev.1
21 /
Oki Data CONFIDENTIAL
1. Configuration
Item
Scanner type Flat bed scanner with automatic document feeder
device (ADF)
Image processor/Controller SH4
Image sensor Color CCD (R,G,B 3 lines)
Light source External electrode-type noble gas fluorescent lamp
Optical resolution 600dpi X 600dpi
Output resolution 600dpi X 600dpi, 300dpi X 300dpi
Input level (A/D conversion) 48 bits (R,G, B, each 16 bits)
Output level 24 bits (R,G,B, each 8 bits) color, 8 bits grayscale, 4
bits CMYK,.1 bit monochrome
Document size Flat bed Maximum A3 (Automatic detectable sizes: A3SEF,
B4SEF, A4SEF/LEF, B5SEF/LEF, A5SEF/LEF), A5, B5,
Letter
ADF 50 sheets (80 g/m2) A4, B5, Letter/25 sheets (80 kg/
m2) A3, B4
Document
thickness
Flat bed 14 mm 14mm
ADF 52-105g/m
2
Maximum
scanning range
Flat bed Maximum 297 mm
ADF Maximum width 297 mm, Minimum document 128.5 x
148.5 mm
ADF Single side Yes, 50 sheets (80g/m2)
Both-sided None
Scanning speed During ADF scanning, Single side 34 pages/minute (at
A4, 300 dpi, same magnification)
Warm-up time 50 ms or less
Life MTBF 5,000 hours or more
MTTR Less than 30 minutes
Flat bed 5 years or 300,000 times of scan
ADF 5 years or 80,000 pages of scan
Fluorescent lamp 1,000 hours (Light-ON accumulative hours)
Attachment file format PDF (JPEG compressed) format, JPEG (JFIF) format,
Multi-page format TIFF (Non-compression/G3/G4
compressed)
Supported driver TWAIN, WIA
Scanner section specifications
Item
Connection Ethernet 10BaseT/100BaseTX automatic negotiation
Communication protocol TCP/IP V4, TCP/IP V6, LPR, Port9100, IPP, FTP, SMTP,
POP3, HTTP, HTTPS, Telnet, NetBIOS over TCP,
SNMP Trap, SNMPv1, SNMPv3, DHCP/BOOTP, DNS,
DDNS, WINS, SLP, UPnP, Bonjour, SNTP, ODNSP,
SMB, CIFS, Q-Server over IP, Q-Server over IPX,
R-Printer, N-Printer, NCP, PAP, NBP, LDAP, Kerberos
Supported browser Microsoft Internet Explorer Ver 5.5 or higher
Netscape Navigator Ver 6.0 or higher
Required setup information,
configuration and others
IP address, sub net mask, gate way, SMTP/POP3
server, FTP server, Web server
Output/Input switch Automatic
Network specifications

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
