4. Part Replacement
4.2.3.8 ID motor/paper feed motor/ID lift-up motor
(1) Remove the Cover-Side-R. (Refer to chapter 4.2.3.4.)
(2) Remove the plate shield R. (Refer to chapter 4.2.3.7(1) and (2).)
(3) Remove the six screws
and remove the plate shield F .
× 6
(4) Remove the four screws and remove the ID motor .
