Oki MC860 Maintenance Manual

Oki Data CONFIDENTIAL
43967002TH Rev. 1
341 /
7. Troubleshooting
7.5.2.(12) Motor fan error (error code 122, 127, 051)
(12-1) The low voltage power supply fan does not rotate immediately after the power is
turned on.
Check item Check work
Action to be taken at NG
(12-1-1) Wiring conditions of the cables
Cable connection
condition and wiring
condition of the
low voltage power
supply fan and those
of the fuser fan
Check if the connectors are connected
normally or not. Check if extra length of the
cables does not touch the fan blade or not.
Reconnect the
connectors. Correct
the cable wiring
route.
Replace the fan.
(12-2) Duplex fan does not rotate during the Duplex printing.
Check item Check work
Action to be taken at NG
(12-1-1) Wiring conditions of the cables
Cable connection
condition and wiring
condition of the
Duplex fan
Check if the connectors are connected
normally or not. Check if extra length of the
cables does not touch the fan blade or not.
Reconnect the
connectors. Correct
the cable wiring
route.
Replace the fan.
24V fuse F501 of
the Duplex PCB
(V7Y PCB)
Check if the fuse F501 has blown out or
not.
Replace the Duplex
PCB (V7Y PCB).
24V power supplied
to the Duplex PCB
(V7Y PCB).
Check if the fuse F1 of the PU PCB has
blown out or not.
Replace the PU
PCB.
(12-3) All fans of the printer do not rotate.
Check item Check work
Action to be taken at NG
(12-3-1) 24V power supply
PU PCB fuses F2,
F4
Check if the fuses F2 and F4 are not open-
circuit or not.
Replace the PU
PCB.
24V power that is
supplied to the PU
PCB.
Check that power supply circuit has no
short-circuit at the POWER connector
of
the POWER PCB.
Pin-4, -5, -6: 24V
Pin-8: 0VL
Pin-1, -2, -3: 0VP
Replace the low
voltage power
supply unit.
7.5.2.(13) Print speed is slow. (Performance is low.)
(13-1) Print speed decreases.
Check item Check work
Action to be taken at NG
(13-1-2) Media Weight setting
Media Weight that
is specified for the
print
Check if the wrong Media Weight has been
specified or not.
Correct the Media
Weight.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
