Oki MC860 Maintenance Manual

43967002TH Rev.1
220 /
Oki Data CONFIDENTIAL
5. Maintenance Menu
5.4.2 LCD test
Displays the test pattern on the LCD in order to check if there is dead pixel on the LCD.
5.4.2.1 Operating procedure
The following three kinds of test pattern can be displayed. To select the test patterns, press
the [SETUP] key.
To exit the LCD test, press the [Reset] key to return to the panel maintenance screen.
Press the [SETUP] key.
5.4.3 Control panel key test
Checks if the MFP responds normally when the hardware key and the software key on the
control panel is pressed, by observing the LCD screen if the pressed key is displayed or not
on the LCD screen.
This test aims at checking of all keys. Therefore, all keys should be pressed in the specified
order in order to check that all keys have been pressed.
5.4.3.1 Operating procedure
When this test is selected, the panel key test screen is displayed as shown below. Press all of
the keys in the specified order as shown in the picture below.
Press the [SETUP] key.
Press the [SETUP] key.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
