Oki MC860 Maintenance Manual

43967002TH Rev.1
240 /
Oki Data CONFIDENTIAL
5. Maintenance Menu
5.10.3.2 Normal self-diagnostic mode (Level 1)
Menus that are contained in the normal self-diagnostic mode are shown below.
Item Self-diagnostic menu Adjustment contents Maintenance
utilities
1 Switch scan test SWITCH SCAN Input sensor and switch
check
No.23
2 Motor clutch test MOTOR&CLTCH
TEST
Motor and clutch
operational test
No.24
3 Executing test
print
TEST PRINT PU internal test pattern
print
Use of this
menu item is
prohibited.
4 Color registration
correction test
REG ADJUST TEST Color registration error
correction system, normal
or defective
No.25
5 Density correction
test
DENS ADJ TEST Density error correction
system, normal or defective
Use of this
menu item is
prohibited.
6 Consumable item
counter display
CONSUMABLE
STATUS
Consumable items,
consumption status display
No.28
7 Consumable item
accumulative
counter display
PRINTER STATUS Consumable items,
accumulative consumption
status display
No.28
8 Factory/Shipping
mode switching
FACTORY MODE
SET
Factory mode or Shipping
mode switching
No.29
9 FUSE status
check
Status display of respective
fuses
Use of this
menu item is
prohibited.
10 Engine parameter
setting
SENSOR SETTING Sets valid or invalid of error
detection using various
sensors
No.30
11 LED head serial
number display
LED HEAD DATA Display of LED head serial
number
Use of this
menu item is
prohibited.
5.10.3.2.1 How to enter self-diagnostic mode (Level 1)
Note! To enter the system maintenance menu mode, entry of password is
required. Refer to table 5-1.
1. From the service menu, select [Printer Maintenance] and [Engine Diag Mode] to
enter the self-diagnostic mode.
2. When the screen enters the self-diagnostic mode (Level 1), the "DIAGNOSTIC
MODE” is displayed.
3. The characters XX XX XX of “DIAGNOSTIC MODE XX XX XX” that are
displayed on the display window means the PU firmware version. Setting
value of the FACTORY WORKING MODE is displayed in the lower right
of the screen. Normally, “SHIPPING” - S-MODE is displayed.
4. Press either (2) key or (8) key to move to the respective self-diagnostic
items. (Menu item rotates when either (2) key or (8) key is pressed.)
5.10.3.2.2 How to exit self-diagnostic mode
1. While the [DIAGNOSTIC MODE] display is shown on the screen, press the (4) key
to return to the service menu.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
