Oki MC860 Maintenance Manual

Oki Data CONFIDENTIAL
7. Troubleshooting
43967002TH Rev. 1
362 /
7.5.5.3 Cannot create Certificate
When Certificate cannot be created, the following causes are probable.
Take an appropriate measure by referring to the following items.
* Req
uired input items are not fully entered
Refer to section “7.5.5.3.1 Required input items are not fully entered.”
* The printer is printing.
Refer to section “7.5.5.3.2 The printer is printing.
7.5.5.3.1 Required input items are not fully entered.
Unless all of the required input items are fully entered, Certificate cannot be created.
When creating Certificate, entry into the items of Common Name, Organization, Locality,
State/Province, Country/Region is the must item. (Entry into Organizational Unit can be
omitted.)
S
ol
ution: Enter the appropriate value into all of the required input items, and execute
creation of Certificate.
For
more details of the input items, refer to the User’s Manual (Advanced
edition).
7.5.5.3.2 The printer is printing.
Certificate cannot be created while printing is in progress. (Print operation has priority).
Solution: Create Certificate when all other operations are complete.
During creation of self-sign certification, during creation of CSR for Certificate of
certification authority, and during installation of Certificate, the printer must not
perform any other operations (such as printing) until the operation is complete
(creation of self-sign certification is complete, creation of CSR is complete, and
installation of Certificate is complete).
7.5.5.4 Installation of Certificate is not possible
When installation of Certificate fails, the following causes are probable.
Take an appropriate measure by referring to the following items.
* Use
r has changed the IP address of a printer to other IP address than the “IP
address during creation of CSR”.
Refer to section “7.5.5.4.1 IP address of the printer has been changed”.
* “Network card is initialized” while user is applying issuance of Certification to
certification authority (i.e., in the state of Waiting for Installation of Certificate).
Refer to section “7.5.5.4.2 “Network card is initialized”.
* “Deletion of CSR” was executed while user is applying issuance of Certification
to certification authority (i.e., in the state of Waiting for Installation of Certificate).
Refer to section “7.5.5.4.3 “Deletion of CSR” is executed”.
* Intermediate Certificate is installed.
Refer to section “7.5.5.4.4 “Installation of intermediate Certificate” is
desired”.
7.5.5.4.1 User has changed the IP address of a printer
If IP address of a printer is changed to other IP address than the “IP address during creation
of CSR”, error is issued and installation of Certificate become impossible.
If the changed setup is only the “IP address of printer”, error will not be issued if the IP
address is returned to the original address.
S
ol
ution: Return the IP address of printer back to the “IP address during creation of CSR”,
and then install Certificate.
Note! Do not change any setup of printer while creation of Certificate of certification
au
thority is in progress (during the period starting from creation of CSR up
until installation of Certificate). If changed, the already issued Certificates
become invalid necessitating re-setup starting from the very beginning. If
printer setup is changed after Certificate is obtained, the “Security warning” is
displayed on the web browser.
I
f
IP address of printer is changed, the Certificate becomes invalid. In the case
of Certificate of certification authority requiring some charge for issuance,
another charge may be required for creating Certificate once again. For
details, contact certification authority.).

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
