Oki MC860 Maintenance Manual

43967002TH Rev.1
251 /
Oki Data CONFIDENTIAL
5. Maintenance Menu
5.10.3.8 Consumable item counter display
This self-diagnostic menu is used to display the consumption status of the consumable items.
1. Enter the self-diagnostic mode and press the (2) key or (8) key until
[CONSUMABLE STATUS] is displayed on the screen. Then, press the (6) key.
(The (2) key increments the test item and (8) key decrements the test item.)
2. When
the (2) key or (8) key is pressed, consumption status of the consumable
items are displayed in order. (Pressing the
( ) key
or the (#) key is invalid.)
3. When the (4) key is pressed, the screen exits the test. (Screen returns to the
item 1 condition.)
Upper column
of display
window
Lower column of
display window
Format Unit Details
K-ID UNIT ********IMAGES DEC Images Number of rotations up to the
present time since the new ID
UNIT for each color has been
installed is displayed after
the data is converted to the
equivalent value of A4, 3Page/
Job.
Y-ID UNIT ********IMAGES DEC Images
M-ID UNIT ********IMAGES DEC Images
C-ID UNIT ********IMAGES DEC Images
FUSER UNIT ********PRINTS DEC Prints Number of sheets up to the
present time since the new
FUSER unit has been installed.
TR BELT UNIT ********IMAGES DEC Images Number of sheets up to the
present time since the new Belt
UNIT has been installed.
K-TONER
(FULL)
********% DEC % Amount of consumption of the
respective color toners are
displayed.
Y-TONER
(FULL)
********% DEC %
M-TONER
(FULL)
********% DEC %
C-TONER
(FULL)
********% DEC %
Upper column
of display
window
Lower column of
display window
Format Unit Details
M-WASTE
TNR CNT
********TIMES DEC Times Amount of waste toner is
displayed.
* When it reaches 32 times, the
Waste toner FULL is issued.
C-WASTE
TNR CNT
********TIMES DEC Times
K-STC MODE
CNT
********TIMES DEC Times Number of printed character dot
counts for the respective toners
are displayed. (Accumulative
value since the MFP has started
running.)
Y-STC MODE
CNT
********TIMES DEC Times
M-STC MODE
CNT
********TIMES DEC Times
C-STC MODE
CNT
********TIMES DEC Times
K OVER RIDE
CNT
********TIMES DEC Times Accumulative number of times
of the toner cartridges for
respective colors are displayed.
Y OVER RIDE
CNT
********TIMES DEC Times
M OVER RIDE
CNT
********TIMES DEC Times
C OVER RIDE
CNT
********TIMES DEC Times

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
