Oki MC860 Maintenance Manual

43967002TH Rev.1
245 /
Oki Data CONFIDENTIAL
5. Maintenance Menu
5.10.3.5 Test print
This self-diagnostic menu is used to print the test pattern contained in the PU. Other test
patterns are contained in the controller
This test print cannot be used to check the print quality.
To diagnose the abnormal image, refer to item 7.
1. Enter
the self-diagnostic mode (Level 1) and press the (2) key or (8) key until
[TEST PRINT] is displayed in the top of the screen. Then, press the (6) key. (The
(2) key increments the test item and (8) key decrements the test item.)
2.
T
he setting items that are applicable to the test print only are displayed in
the lower column of display window. Press the (2) key or the (8) key until the
corresponding item is displayed. Then, press the (6) key. (The (2) key increments
the item and (8) key decrements the item.) (When the setting value for each item
is not required [Default setting], advance to item 2.)
3.
K
eep pressing the (2) key or the (8) key, and press the (6) key at the item that
is set in item 2. The setup item is displayed in the upper column, and the setting
value is displayed in the lower column of the display window. Pressing the (2)
key increments the setting value. Pressing the (8) key decrements the setting
value. (The setting value that is displayed last is applied.) Pressing the (4) key
determines the setting value, and the screen returns to item 2.) Repeat item 3
as required.
Display Setup value Function
PRINT EXECUTE –
Pressing the (4) key starts printing/Pressing
the (#) key ends printing (in page unit).
TEST PATTERN 0 0 White paper print
1 to 7 Refer to next page. (Pattern print)
8 to 15 White paper print
TEST CASSETTE TRAY1 Select the paper feed source.
If TRAY2 is not installed, TRAY2 is not displayed.
TRAY2
MFP
PAGE 0000 Setting the number of test prints.
COLOR ON Selecting color or monochrome print.
* ON is specified, ON/OFF setting for each color
appears.
OFF
DUPLEX 2 PAGES STACK Duplex print is executed with two sheets stack.
Duplex print OFF select
Duplex print is executed with single sheet stack.
OFF
1PAGES STACK
MONO SPEED LOW Selecting monochrome print speed.
LOW: 30ppm
HIGH: 34ppm(A4),33ppm(Letter)
HIGH
• is the initial value. The set item is valid in this test mode only.
(It is not saved in EEPROM.)
Note!
PAGE setting …………………… Pressing the (2) key or the (8) key shifts the digit. When the (
)
key is pressed, the setting value increments. Pressing the # key
decrements the setting value. If test print is executed with the print
number setting “0000”, print will continue infinitely. Be careful not to
set “0000”.
COLOR setting …………………… When the (6) key is pressed while set to ON, the following contents
are displayed on the panel screen.
Pri
nt setting of each color………… Pressing the (2) key or the (8) key shifts the value.
Pressing the (
) key or the (#) key enables operator to switch
between ON and OFF setting.
Pressing the (4) key returns the screen to operator panel display.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
