43967002TH Rev.1
246 /
Oki Data CONFIDENTIAL
5. Maintenance Menu
4. When the (6) key is pressed while “PRINT EXECUTE” is being displayed in the
lower column of display window, the test print is executed with the setting values
that are set in items 2 and3.
Pressing the (#) key stops the test pr
int
If any of the following alarms is detected while the test print is in progress
or during test print startup, it is displayed on the panel and the test print is
interrupted. (For error details, refer to item 5.12.1.14 Panel display details.) For
the PU test print, different comment is displayed. )
Panel display Details
PAPER END
SELECTED TRAY
Paper absent
DUPLEX UNIT IS
NOT INSTALLED
DUPLEX not installed.
SELECTED TRAY IS
NOT INSTALLED
Selected tr
ay installed.
REMOVE PAPER
OUT OF DUPLEX
DUPLEX internal error
Print pattern. (It cannot be used for print quality check = PQ.)
0, 8 to 15 ------ White paper print
Pattern 1 Pattern 2
Note! If the solid print data (pattern 7)
that is contained in the local print
function is used for test print with
100% setting of each color, it causes
offset. To prevent offset, select the
print setting of each color so that
the number of colors to be printed at
the same time should be limited to 2
colors or less as specified in item 3
of item 5.3.2.5.
Pattern 3 Pattern 4
Pattern 5 Pattern 6
Pattern 7
To Next Page
