3. Installation
3.7 Menu list
Copy standby screen
The shaded portion shows the default setup value when shipped from the factory.
Item Contents
others
N-in-1 N-in-1 OFF
2-in-1
4-in-1
8-in-1
Multiple pages of document can
be laid out and assembled onto a
single page by this setup.
Tray Auto
MP tray
Tray 1
Tray 2
Tray 3
Select a document feeding tray.
Layout Hor
izontal
Vertical
Select desired setting for
arrangement.
This arrangement cannot be
selected when number of sheets
of document is set to “OFF”, or “2
sheets”.
Repeat Repeat OFF Set number of times of repeating
copying the same document into a
single page.
Tray MP tray
Tray 1
Tray 2
Tray 3
Select a document feeding tray.
Book Copy Doc Bind OFF
Left
Right
Select orientation of binding
direction when copying two-page
spread document by one page after
another.
Tray Auto
MP tray
Tray 1
Tray 2
Tray 3
Select a document feeding tray.
The shaded portion shows the default setup value when shipped from the factory.
Item Contents
others
Margin Setup ON
OFF
Set Enable/Disable binding margin.
Left
(Front)
0~±25mm
(1mm/Step)
0
0~±1.0inch
(0.1inch/Step)
Set distance of movement of copied
output image toward right on the
front side of copy paper.
(Display in units of mm or display
in units of inch can be switched by
changing the unit of display on the
system setup).
Top
(Front)
0~±25mm
(1mm/Step)
0
0~±1.0inch
(0.1inch/Step)
Set distance of movement of copied
output image toward bottom on the
front side of copy paper.
(Display in units of mm or display
in units of inch can be switched by
changing the unit of display on the
system setup).
Left
(Back)
0~±25mm
(1mm/Step)
0
0~±1.0inch
(0.1inch/Step)
Set distance of movement of copied
output image toward right on the
front side of copy paper.
(Display in units of mm or display
in units of inch can be switched by
changing the unit of display on the
system setup).
Top
(Back)
0~±25mm
(1mm/Step)
0
0~±1.0inch
(0.1inch/Step)
Set distance of movement of copied
output image toward bottom on the
rear side of copy paper.
(Display in units of mm or display
in units of inch can be switched by
changing the unit of display on the
system setup).
Edge Erase Edge Erase ON
OFF
Select whether or not to erase
shade that is created in the
surrounding area of the thick
document such a book.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
