5. Maintenance Menu
Setup item
Administrator setup
Network default setting
HDD initialization
(All area formatting)
HDD formatting
(Common partition)
HDD formatting
(PCL partition)
HDD formatting
(PS partition)
HDD data complete erase
FLASH initialization
Language initialization
Setup value initialization
Complete erasure of
individual personal
information
Group counter – Reset *1
Job log deletion
Log
Billing log
CL CL
Job log (HDD)
CL CL CL
Debug log (HDD)
CL
Error log (HDD)
CL
Error log (FLASH)
Dial history
CL CL
E-mail address history
CL CL
Fax communication result
information
CL CL
Counter
Group counter (Open to user)
CL
Maintenance counter (Life
related)
Main counter (Dealer
tabulation related)
Print tabulation password
FW
Scanner unit F/W (including
Fax)
NIC-F/W (including Web page)
Others
Mirror carriage transport mode
Scanner factory adjustment
Stored image
CL CL
Maintenance switch
(Confidential)
*1 The group counter – Reset is confidential and menu is not open in FCS.
*4 When HDD Disable is set, only administrator can log on.
(Because the access control mode setup values is stored in Flash, but the user
information is not stored in HDD.)
5.11.2 Initialization by service engineer
5.11.2.1 Initialization operation by service engineer
The initialization operations that can be performed by service engineer are shown below.
Initialization operation Description
Format HDD
(Boot sector erase)
This operation can be executed by selecting the menus:
[Service Maintenance] - [System Maintenance] - [Format
HDD]. When this operation is executed, the screen exits the
menu and initialization of the HDD starts.
Format Flash ROM
(System area initialization)
This operation can be executed by selecting the menus:
[Service Maintenance] - [System Maintenance] - [Format
Flash ROM]. When this operation is executed, the screen
exits the menu and formatting of the Flash device that is
resident (on-board) installed in the MFP starts.
Administrator password reset Returns the administrator password that has been set by
user, to the default value.
This operation can be executed by selecting the menus:
[Service Maintenance] - [System Maintenance] - [Change
Password] .
This setting is executed for the propose of initializing the
administrator password by service engineer in the case when
user forgets the administrator password.
All Reset Returns the contents of the EEPROM, FLASH ROM and
HDD to the factory shipment setting (factory default) value.
This operation can be executed by selecting the menus:
[Service Maintenance] - [System Maintenance] - [All Reset].
This setting is executed for the propose of erasing by dealer
for an example, the information of the previous user who has
been using the MC860, in the case when dealer is going to
lend the MC860 to other client.
OKIUSER change Changes the destination of the MC860.
This operation can be executed by selecting the menus:
[Service Maintenance] - [System Maintenance] - [OKIUSER].
Country code change Select the country in which the MC860 is going to be
installed.
This operation can be executed by selecting the menus:
[Service Maintenance] - [Fax Maintenance] - [Country Code].

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
