5. Maintenance Menu
5.8.10.2 Tonal send test
The tonal signal and image data as shown in the following table are sent for the test.
Contents
NONE V34_2800_7200
400HZ V34_2800_9600
600HZ V34_2800_12000
1100HZ V34_2800_14400
1300HZ V34_2800_16800
2100HZ V34_2800_19200
3000HZ V34_2800_21600
3400HZ V34_2800_24000
FSK_WHITE V34_2800_26400
FSK_BLACK V34_3000_4800
FSK_W1_B1 V34_3000_7200
V27_1200_2400 V34_3000_9600
V27_1600_4800 V34_3000_12000
V29_2400_7200 V34_3000_14400
V29_2400_9600 V34_3000_16800
V17_2400_7200_W1_B0 V34_3000_19200
V17_2400_7200_W1_B1 V34_3000_21600
V17_2400_7200_W1_B4 V34_3000_24000
V17_2400_7200_W0_B1 V34_3000_26400
V17_2400_7200_W4_B1 V34_3000_28800
V17_2400_9600_W1_B0 V34_3200_4800
V17_2400_9600_W1_B1 V34_3200_7200
V17_2400_9600_W1_B4 V34_3200_9600
V17_2400_9600_W0_B1 V34_3200_12000
V17_2400_9600_W4_B1 V34_3200_14400
V17_2400_12000_W1_B0 V34_3200_16800
V17_2400_12000_W1_B1 V34_3200_19200
V17_2400_12000_W1_B4 V34_3200_21600
V17_2400_12000_W0_B1 V34_3200_24000
V17_2400_12000_W4_B1 V34_3200_26400
Contents
V17_2400_14400_W1_B0 V34_3200_28800
V17_2400_14400_W1_B1 V34_3200_31200
V17_2400_14400_W1_B4 V34_3429_4800
V17_2400_14400_W0_B1 V34_3429_7200
V17_2400_14400_W4_B1 V34_3429_9600
V34_2400_2400 V34_3429_12000
V34_2400_4800 V34_3429_14400
V34_2400_7200 V34_3429_16800
V34_2400_9600 V34_3429_19200
V34_2400_12000 V34_3429_21600
V34_2400_14400 V34_3429_24000
V34_2400_16800 V34_3429_26400
V34_2400_19200 V34_3429_28800
V34_2400_21600 V34_3429_31200
V34_2800_4800 V34_3429_33600

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
