43967002TH Rev.1
262 /
Oki Data CONFIDENTIAL
5. Maintenance Menu
5.13 Maintenance utilities
Adjustments shown in Table 5-2 can be performed by the maintenance utilities. Details of the
maintenance utilities are described below.
(1) Maintenance utilities, Operation manual:
426
78801FU01 Rev22 or higher (Japanese)
42678801FU02 Rev5 or higher (English)
(2) Maintenance utilities programs are shown below
Applicable OS Filename Model No.
For Win9xMe/NT/2000/XP/Vista
(Japanese/English)
MuWin.zip 42678801FW01
Rev1 or higher
Table 5-2 Adjustment items of maintenance utilities
Item Adjustment contents
Maintenance
utilities,
Operation
manual, Item
number
Operation on
Operator panel
(Item numbers
correspond to those
of Maintenance
manual.)
1 PU board
replacement
Copying the EEPROM of PU PCB
Adjustment purpose: Above data is copied
to another PCB when the PU PCB is going
to be replaced by other PU PCB due to
maintenance replacement.
Item 2.4.1.1.1 Use of this menu item
is prohibited.
2 PU serial
number
setting
Rewriting the MFP serial number saved in
PU
Adjustment purpose: If copying of EEPROM
data of the PU PCB is impossible (due to I/F
error, etc.,), above setting is made on the
maintenance replacement PCB.
Item
2.4.1.1.2.2
Use of this menu item
is prohibited.
3 Factory/
Shipping
mode
Factory mode or Shipping mode switching
Adjustment purpose: If copying of EEPROM
data of the PU PCB is impossible (due to
I/F error, etc.,), above setting is made on
the maintenance replacement PCB. Default
setup of the maintenance replacement PCB
remains in the Factory mode in most cases,
the Shipping mode should be set by using
this function.
Item
2.4.1.1.2.3
Item 2.4.1.2.2
Item 5.3.2.10
Item Adjustment contents
Maintenance
utilities,
Operation
manual, Item
number
Operation on
Operator panel
(Item numbers
correspond to those
of Maintenance
manual.)
4 CU PCB
replacement
Rewriting EEPROM setup value of CU PCB
Adjustment purpose: Above data is rewritten
into another PCB when the CU PCB is going
to be replaced by other CU PCB due to
maintenance replacement.
Item 2.4.1.1.3 Use of this menu item
is prohibited.
5 Serial number
information
setting
Selection of printer serial number and
output mode recorded in CU, and rewriting
MFP serial number
Item
2.4.1.1.4.3
Use of this menu item
is prohibited.
6 Scanner PCB
replacement
Copying the EEPROM of scan PCB
Adjustment purpose: Above data is copied
to another PCB when the scan PCB is going
to be replaced by other scan PCB due to
maintenance replacement.
Item 2.4.1.1.5 Use of this menu item
is prohibited.
7 Setup
information of
PCB item
Serial number information and Factory/
Shipping mode check.
Item 2.4.1.1.7 Use of this menu item
is prohibited.
8 USB software
update
USB software update Item 2.4.2.2.1 Use of this menu item
is prohibited.
9 NIC software
update
NIC software update Item 2.4.2.2.2 Use of this menu item
is prohibited.
10 NIC Web
Page update
NIC Web Page update Item 2.4.2.2.4 Use of this menu item
is prohibited.
11 Mac address
setting
Mac address setting Item 2.4.2.2.5 Use of this menu item
is prohibited.
12 Consumables
item counter
maintenance
function
Consumable item counter display
Drum counters (Y, M, C, K)
Fuser counter
Belt counter
Toner counters (Y, M, C, K)
Adjustment purpose: Values of the
respective consumable item counters are
copied when consumable item that is still in
the midst of usage is going to be used by
other MFP.
Item 2.4.1.2.1 Use of this menu item
is prohibited.
To Next Page
