Oki MC860 Maintenance Manual

43967002TH Rev.1
263 /
Oki Data CONFIDENTIAL
5. Maintenance Menu
Item Adjustment contents
Maintenance
utilities,
Operation
manual, Item
number
Operation on
Operator panel
(Item numbers
correspond to those
of Maintenance
manual.)
17 Destination/
PnP
information
setting
Printer (CU) destination, device ID, USB ID
setting/check
Item 2.4.1.2.9 Item 5.4.3
18 Send to File
function
Send to the Specified file Item 2.4.1.2.12
19 Consumable
item counter
display
Consumable item counter current value
check
Item 2.4.1.3.1 Item 5.1 ENG
STATUS PRINT
20 Menu setup
value check
Setup value of the respective menus that
are set in printer (CU) is displayed.
Item 2.4.1.3.2 Menu map print
(Refer to User’s
Manual.)
21 Printer
information
check
Printer Mac address and various F/W
versions are checked.
Item 2.4.1.3.3 Menu map print
(Refer to User’s
Manual.)
22 Installed
CPU/memory
value check
Information of CPU and memory that are
installed in printer (CU) are checked.
Item 2.4.1.3.4 Menu map print
(Refer to User’s
Manual.)
23 Test print Local print function execution and specifying
File send
Adjustment purpose: Operation check of
printer standalone and sending download
file
Item 2.4.1.4.1 Each local print
(Refer to System
Specifications.)
24 Switch scan
test function
Execution of switch scan test
Adjustment objective: Operation check of
the respective sensors
Item 2.4.1.5.1 Use of this menu item
is prohibited.
25 Motor clutch
test function
Execution of motor clutch test
Adjustment objective: Operation check of
the respective motors and clutches.
Item 2.4.1.5.2 Use of this menu item
is prohibited.
26 Color
registration
correction
test function
Execution of color registration error
correction
Item 2.4.1.5.3 Use of this menu item
is prohibited.
Item Adjustment contents
Maintenance
utilities,
Operation
manual, Item
number
Operation on
Operator panel
(Item numbers
correspond to those
of Maintenance
manual.)
27 Density
correction
function test
Execution of density correction test Item 2.4.1.5.4 Use of this menu item
is prohibited.
28 Automatic
density
correction
control
parameter
setting
[Do not use]
Setting the automatic density correction
control parameter
[Do not use] [Do not use]
29 Counter
display
Checking reading of the consumable items
counter, consumables continue counter and
waste toner counter.
Item 2.4.1.5.6 Use of this menu item
is prohibited.
30 Local
parameter
setup/display
function
Factory mode or Shipping mode switching
FUSE status check
Item 2.4.1.5.7 Use of this menu item
is prohibited.
31 Engine
parameter
setup
function
Setting values of the engine parameter
items
Item 2.4.1.5.8 Use of this menu item
is prohibited.
32 Media
transport
parameter
setup
function
Media transport parameter setup value
setting 2
Item 4.1.5.9 Use of this menu item
is prohibited.
Note! [Do not use] Do not operate and do not set the item. There is danger of
operating abnormally.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
