Oki MC860 Maintenance Manual

43967002TH Rev.1
244 /
Oki Data CONFIDENTIAL
5. Maintenance Menu
Table 5-4
Unit name display Drive restriction conditions Remarks
ID MOTOR Drives when all of the IDs (K/Y/M/C) are
removed.
−
BELT MOTOR Drives when all of the IDs (K/Y/M/C) are
removed.
−
FUSER MOTOR − −
FUSER MTR REV − −
FUSER_RLS − −
REGIST MOTOR − −
T1 HOPPING MOTOR − −
FRONT MOTOR − −
REGIST SHUTTER − −
EXIT SOLENOID − −
DUPLEX MOTOR − −
DUPLEX CLUTCH − −
T2 HOPPING MOTOR − OPTION
T2 FEED CLUTCH − OPTION
T3 HOPPING MOTOR − OPTION
T3 FEED CLUTCH − OPTION
ID UP/DOWN TOP/FRONT covers, closed condition −
LV FAN TEST − −
FUSER FAN TEST − −
FUSER2 FAN TEST − −
DUPLEX FAN TEST − OPTION
PS FAN TEST − −
Note! Display while the ID UP/DOWN is in progress.
***: Number of times of execution

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
