Oki MC860 Maintenance Manual

43967002TH Rev.1
242 /
Oki Data CONFIDENTIAL
5. Maintenance Menu
Table 5-3 SWITCH SCAN details
Upper column of display
window
1 2 3 4
Details
Lower column of
display window
Details
Lower column of
display window
Details
Lower column of
display window
Details
Lower column of
display window
PAPER ROUTE : PU Entrance sensor 1
H: Paper absent
L: Paper present
Entrance sensor 2
H: Paper absent
L: Paper present
Write sensor
H: Paper absent
L: Paper present
Unload sensor
H: Paper absent
L: Paper present
TONER SENS Toner sensor K
H: Light interrupt
L: Reflect
Toner sensor Y
H: Light interrupt
L: Reflect
Toner sensor M
H: Light interrupt
L: Reflect
Toner sensor C
H: Light interrupt
L: Reflect
CVO UP_LU_FU Cover open switch
H: Close
L: Open
REG L/R_OHP_WG
Color registration
error sensor L
AD value:
***H
Color registration
error sensor R
AD value:
***H
HT THERMISTER
Fuser thermistor,
Upper sensor
AD value:
***H
Fuser thermistor,
Lower
AD value:
***H
Fuser thermistor, Upper
sensor, side
AD value:
***H
Heater frame
thermistor
AD value:
***H
HUM_TEMP_DEN Humidity sensor
AD value:
***H
Temperature sensor
AD value:
***H
Density sensor (K)
AD value:
***H
Density sensor
(YMC)
AD value:
***H
BELT_T Belt thermistor
AD value:
***H
ID UP/DOWN Up Down sensor
H: Up
L: Down
RFID COLOR*
1
FID antenna K
UID:
***H
RFID antenna Y
UID:
***H
RFID antenna M
UID:
***H
RFID antenna C
UID:
***H
F-RL FI BL DT-DC Fuser release sensor
H: ON
L: OFF
Fuse entrance
sensor
T1 PE_PNE_CVO
Tray 1 paper end
sensor
H: Paper absent
L: Paper present
T1 CASETTE SIZE*
2
Size setting switch 1 Port level H, L Size setting switch 2 Port level H, L Size setting switch 3 Port level H, L Size setting switch 4 Port level H, L
T2 PE_PNE_CVO_CA
Tray 2 paper end
sensor
H: Paper absent
L: Paper present
T2 HOP_LF_FED Tray 2 entrance sensor
H: Paper absent
L: Paper present
T2 CASETTE SIZE*
2
Size setting switch 1 Port level H, L Size setting switch 2 Port level H, L Size setting switch 3 Port level H, L Size setting switch 4 Port level H, L
T3 PE_PNE_CVO_CA
Tray 3 paper end
sensor
H: Paper absent
L: Paper present
T3 HOP_LF_FED Tray 3 entrance sensor
H: Paper absent
L: Paper present
T3 CASETTE SIZE*
2
Size setting switch 1 Port level H, L Size setting switch 2 Port level H, L Size setting switch 3 Port level H, L Size setting switch 4 Port level H, L
DUP IN_RA_FNT Duplex input sensor
H: Paper absent
L: Paper present
Duplex rear sensor
H: Paper absent
L: Paper present
Duplex front sensor
H: Paper absent
L: Paper present
DUP SK_CVO
Duplex bottom
sensor
H: Paper absent
L: Paper present
Duplex cover sensor
H: Close
L: Open
<No function> Asterisk (*) is displayed in the lower column of display window.
*
1
L is displayed as [RFID COLOR L] when the cover is opened. Asterisk (*) is displayed in the lower column of display window.
*
2
Refer to 7.7 Paper cassette switches versus Paper size correspondence table. Switch numbers for each size starts from left-most end with 1.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
