6. Periodic Maintenance
5. Remove the fuser unit from the MFP.
Failure to observe the caution may result in
burn injury.
The fuser unit gets very hot. Be very careful not to touch the fuser
unit with your hands.
If it got hot, stop the work and wait until it cools down. After it has
cooled down, start the following steps.
1. Raise the fuser unit lock levers (two levers shown in blue) in the direction
shown by the arrow.
2. Hold the handle of the fuser unit and remove it.
6. Install the fuser unit in the MFP.
For the detailed procedure, refer to the User's Manual – Setup Guide “Replacing
fuser unit”.
7. Return the four image drum cartridges to the MFP gently and
carefully.
8. Close the top cover
.
Handle
Fuser unit lock levers
(shown in blue)
9. Return the document table to the original position.
To Next Page
