Oki MC860 Maintenance Manual

43967002TH Rev.1
3 /
Oki Data CONFIDENTIAL
This is the Maintenance Manual for the Oki Data Color LED MFP MC860series MC860dn/
MC860dtn describing the maintenance procedures. This manual is intended to be used by
the experienced maintenance engineer. For the operating procedure of the Oki Data Color
LED MFP MC860 series MC860dn/MC860dtn, refer to the User’s Manual.
The Oki Data Color LED MFP MC860series MC860dn/MC860dtn is sometimes abbreviated
simply as MC860 or MFP in this manual.
Note! * Contents of this manual can be changed without prior notice.
* There can be errors in this manual even though Oki Data has made
best efforts to create the accurate manual. Oki Data is not liable for
any loss and/or damage that are asserted by user to have been
caused by the repair/adjustment/change which are implemented to
the MFP by using this manual.
* The parts/components that are used in the MFP are delicate and
can be easily damaged if they are not handled in appropriate
method. Oki Data recommends strongly that maintenance of the
MFP should be made by the maintenance engineers who are the
registered member of Oki Data.
* Before starting any work, remove static electricity beforehand.
PREFACE
PREFACE

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
