Oki MC860 Maintenance Manual

43967002TH Rev.1
42 /
Oki Data CONFIDENTIAL
2. Theory of Operation
Counter specifications
Total number of
printed sheets
Number of MPT
printed sheets
Number of tray 1
printed sheets
Number of tray 2
printed sheets
Number of tray 3
printed sheets
Number of color page
printings
Number of monochrome
printed pages
Definition Total number of
printed pages
Number of hopping
from MPT
Number of hopping
from tray 1
Number of hopping
from tray 2
Number of sheets in color
printing
Number of sheets in
monochrome printing
Count method
Converted to A4
equivalent or non-
dependent on size
Counts up after
paper has passed
the write sensor
Count-up when the
MPF (MPT) hopping
has succeeded.
Count up when the
tray 1 hopping has
succeeded.
Count up when the
tray 2 hopping has
succeeded.
Number of sheets that has
passed the fuser unit in color
mode is counted up when
the print job is completed.
(*1)
The value is the A4/Letter
converted value.
Regarding the A4/Letter
conversion, refer to the sheet
“page count rules".
Number of sheets that
has passed the fuser unit
in monochrome mode is
counted up when the print
job is completed. (*1) Even
when a color print speed
is selected, there can be
cases that the print is in
monochrome mode.
The value is the A4/Letter
converted value.
Regarding the A4/Letter
conversion, refer to “rules” of
the A4/Letter conversion.
Handling when paper jam
occurs
Count is not executed during the feed paper (hopping) jam and feed jam (380).
Jams other than those are counted.
Because the total number of printed sheets are counted when top end of paper has passed the write sensor, the
feed jam (380) is included in the condition of not counting the jam if jams are classified by the jam types.
When jam occurs before paper passes the fuser unit, the
jam is not counted. Jams after paper has passed the fuser
unit are counted.
Handling during the
Duplex print
Front and rear
sides of papers are
counted. (+2)
Only table is counted. (+1) It is counted as 2 counts. .
If color page exists within a pair of two pages, the number
of color prints is incremented by +2. If color page does not
exist within a pair of two pages, the number of monochrome
prints is incremented by +2.
Reset condition None None (1) When ROM is replaced by the ROM of different version
(2) When destination is changed
(3) MENU RESET of the system maintenance menu is
executed.
(4) CU PCB replacement F
Location where data is
stored
PU PU PU PU PU CU CU
Menu/Menu Map output
(*2)
Engine Menu Map output (*3) (*3) (*3) − −
* 1. If the main power of MFP is shut down when a jam occurs, the counter is not updated.
* 2. It is not output to the Menu Map if the MFP is in the initial state. Switching the setting to enable outputting the data is possible by operating the system
maintenance menu.
* 3. The Engine Menu Map output is divided into the Engine Menu Print (first page) and the Engine EEPROM Dump Print (last page). However, the number of feed
papers to the respective trays is output (DUMP display) to the latter output only.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
