3. Installation
Fax standby screen
During onhook
The shaded portion shows the default setup value when shipped from the factory.
Item Contents
others
Duplex Scan OFF
Right & left
Top
Set the binding position of document.
Scan sise Auto
A3
B4
A4
A4
B5
A5
Tabloid
Letter
Letter
Tabloid
Legal 14
H.LTR
Set document scanning area.
Croup Tx Group number Select group of destination.
Unregistered groups are grayed-out.
Cont. Scan ON
OFF
Select to inquire or not to inquire if next page
of document is ready.
TTI ON
OFF
Set whether or not to print sender’s name on
document when it is printed at destination.
TTI Select 1:
2:
3:
Select name of sender.
Names of sender as many as three can be
registered by [MPF Setup] - [Administrator
Setup] - [Installation Mode].
When any one of the above is not selected,
the default setup is used.
MCF Report ON
OFF
Set whether or not to print result of
transmission automatically.
Deleyed Tx Date, hour,
minute
Send transmission by specifying time.
The shaded portion shows the default setup value when shipped from the factory.
Item Contents
others
Polling ON
OFF
Set whether or not to set up polling reception.
F Polling Sub address Set sub address.
Password Set password.
F-Code Tx Sub address Set sub address.
Password Set password.
Memory Tx ON
OFF
When it is set to OFF, the real-time
transmission enabling transmission while
scanning document is set.
Dialing Options
Clear
-
Pause
Tone
Prefix
First
transmission
First
transmission
Abbr. dialing
registration
Entry of dialing code using dedicated keys is
possible.
Abbr. registration key enables registration of
abbr. dialing code number directly.
Auto Rx ON
OFF
Set the automatic reception or manual
reception of facsimile reception mode.
Speed Dial 001
500
Select destination of transmission from the
already-registered abbr. dial code numbers.
Doc. Type Normal
Fine
Ext-Fine
Background
Select image quality when scanning
document.

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
