Oki MC860 Maintenance Manual

43967002TH Rev.1
96 /
Oki Data CONFIDENTIAL
3. Installation
The shaded portion shows the default setup value when shipped from the factory.
Item Contents
others Direction Left Edge
Top Edge
Set orientation of document that is set
on glass, and set orientation of image.
Left end Starting origin of horizontal
scanning is set to the left end of image.
Top end Starting origin of horizontal
scanning is set to the top end
(90-degree rotation) of image.
Grayscale OFF
ON
ON Document is scanned in B/W 255
gradations.
OFF Document is scanned in B/W 2
gradations.
FileFormat Color PDF
TIFF
JPEG
XPS
Set file format when scanning in color.
Mono
(Grayscale)
PDF
TIFF
JPEG
XPS
Set file format when scanning in
grayscale.
Mono
(Binary)
PDF
TIFF
Set file format when scanning in
monochrome.
CompresRT Color High
Medium
Low
Set the compression rate when
scanning in color.
Mono
(Grayscale)
High
Medium
Low
Set compression rate when scanning in
B/W with grayscale being set to ON.
Mono
(Binary)
High (G4)
Medium (G3)
Raw
Set compression rate when scanning in
B/W with grayscale being set to OFF.
Edge Erase Edge Erase OFF
ON
Set default setup of selection whether
to erase or not shade that is created
in the surrounding of two-page spread
document.
The shaded portion shows the default setup value when shipped from the factory.
Item Contents
others Edge Erase Width 5~50mm
(1mm/Step)
0.2~2.0inch
(0.1inch/Step)
Set erasing width when erasing frame.
(Display in units of mm or display
in units of inch can be switched by
changing the unit of display on the
system setup).
Erase Center Erase Center OFF
ON
Set default setup of selection whether
to erase or not shade that is created
in the center of two-page spread
document.
Erase Width 1~50mm
(1mm/Step)
0.1~2.0inch
(0.1inch/Step)
Set erasing width when erasing center.
(Display in units of mm or display
in units of inch can be switched by
changing the unit of display on the
system setup).
Contrast -3
-2
-1
0
+1
+2
+3
Set Contrast.
Hue -3
-2
-1
0
+1
+2
+3
Set Color phase.
Saturation -3
-2
-1
0
+1
+2
+3
Set color saturation

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
