Olympus FLUOVIEW FV300 User Manual

SYSTEM OVERVIEW/Software Functional Configuration
III . SYSTEM OVERVIEW
III . 1-13
Page
1-5-4 Identification of Images Depending on the Observation Methods
In many occasions, FLUOVIEW displays image
icons to allow identification of the observation
method used when each image is acquired.
(See table on the left.)
When the [File I/O], [Tile], [Process], [Analyze]
or [Visualize] panel is selected, the icon of the
image selected in the [Display] panel is
displayed in a frame at the top of the function
panel. The image icons are also displayed in the
[Icon] field in the [Files] list box in the [File I/O]
panel or during dragging of an image file.
Use these icons to identify the observation
methods used in image acquisition.
In all observation modes, the icons
for 3 or more channels are identical.
Image Icon Significance
XZ observation
XZ observation, 2-channel mode
Xt observation
Xt observation, 2-channel mode
XZT observation
XZT observation, 2-channel
mode
XY observation
XY observation, 2-channel mode
XYt observation
XYt observation, 2-channel
mode
XYZ observation
XYZ observation, 2-channel
mode
XYZt observation
XYZt observation, 2-channel
mode
Point Scan
Animation image
Stereo 3D image: Image to be
viewed with color eyeglasses.
3 or more channels
TIP
