xx
Introduction
F3SG-R
User’s Manual
4-5-5. Functional Earth Connection 175
Chapter5 Input/Output Circuit and Applications 177
5-1. Input/Output Circuit 179
5-1-1. Entire Circuit Diagram 179
5-1-1-1. F3SG-RA Series 179
5-1-1-2. F3SG-RE Series 181
5-1-2. Input Circuit Diagram by Function 183
5-1-2-1. F3SG-RA Series 183
5-1-2-2. F3SG-RE Series 183
5-2. Wiring Examples(F3SG-RA Series) 184
5-2-1. Standalone F3SG-RA using PNP Outputs 184
5-2-2. Standalone F3SG-RA using NPN Outputs 185
5-2-3. Standard Muting Mode/Exit-Only Muting Mode using PNP Outputs 186
5-2-4. Standard Muting Mode/Exit-Only Muting Mode using NPN Outputs 187
5-2-5. Standard Muting Mode/Exit-Only Muting Mode with two Muting Sensors using PNP Outputs
188
5-2-6. Standard Muting Mode/Exit-Only Muting Mode with two Muting Sensors using NPN Outputs
189
5-2-7. Standard Muting Mode with four Muting Sensors using PNP Outputs 190
5-2-8. Standard Muting Mode with four Muting Sensors using NPN Outputs 191
5-2-9. Standard Muting Mode with F3W-MA (T-Shaped Configuration with 4-Joint Plug/Socket Con-
nector) 192
5-2-10.Exit-Only Muting Mode with F3W-MA (L-Shaped Configuration with 4-Joint Plug/Socket Con-
nector) 193
5-2-11.Pre-Resest Mode using PNP Output 194
5-2-12.Pre-Resest Mode using NPN Output 195
5-2-13.Standalone F3SG-RA with Y-Joint Plug/Socket Connector using PNP outputs 196
5-2-14.Standalone F3SG-RA with Y-Joint Plug/Socket Connector using NPN outputs 197
5-2-15.F3SG-RA with Y-Joint Plug/Socket Connector in Standard Muting Mode/Exit-Only Muting
Mode using PNP outputs 198
5-3. Wiring Examples (F3SG-RE Series) 199
5-3-1. Short Mode 199
5-3-2. Long Mode 200
5-3-3. Standalone F3SG-RE with Y-Joint Plug/Socket Connector 201
5-4. Connectable Safety Control Units 202
Chapter6 Checklists 203
6-1. Pre-Operation Checklists 204
6-1-1. Checklists 204
6-1-1-1. Installation Condition Check 204
6-1-1-2. Wiring Check Before Power Is Turned ON 204
To Next Page
