Omron F3SG series User Manual

xxi
F3SG-R
User’s Manual
Introduction
E
6-1-1-3. Operation Check While the Machine Is Stopped 205
6-1-1-4. Checking that Hazardous Parts Stop While the Machine Operates 206
6-2. Maintenance Checklists 207
6-2-1. Checklists 207
6-2-1-1. Inspection at Startup and When Changing Operators 207
6-2-1-2. Checking that Hazardous Parts Stop While the Machine Operates 208
6-2-1-3. Items to Inspect Every 6 Months or When Machine Settings Are Changed 208
Chapter7 Appendix 211
7-1. Troubleshooting 212
7-1-1. Lockout State 213
7-1-1-1. Description 213
7-1-1-2. Troubleshooting 214
7-1-2. Warning 218
7-1-2-1. Description 218
7-1-2-2. Troubleshooting 218
7-1-2-3. Muting Sequence Error Indication 219
7-1-2-4. Interlock Sequence Error Indication 220
7-2. Optional Accessories(Sold Separately) 221
7-3. Glossary 228
7-4. Revision History 232

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
