Omron F3SG series User Manual

12
Chapter1 Ratings/Specifications
F3SG-R
User’s Manual
Overview and Specifications
Input Voltage
ON
Voltage
TEST:
24 V Active: 9 V to Vs (sink current 3 mA max.) *
0 V Active: 0 to 3 V (source current 3 mA max.)
MUTE A/B:
PNP: Vs to Vs-3 V (sink current 3 mA max.) *
NPN: 0 to 3 V (source current 3 mA max.)
RESET:
PNP: Vs to Vs-3 V (sink current 5 mA max.) *
NPN: 0 to 3 V (source current 5 mA max.)
Operating Range Select Input:
Long: 9 V to Vs (sink current 3 mA max.) *
Short: 0 to 3 V (source current 3 mA max.)
OFF
Voltage
TEST:
24 V Active: 0 to 1.5 V or open
0 V Active: 9 V to Vs or open
MUTE A/B, RESET:
PNP: 0 to 1/2 Vs, or open *
NPN: 1/2 Vs to Vs, or open *
* The Vs indicates a supply voltage value in your environment.
Overvoltage Category (IEC
60664-1)
II
Indicators
Refer to 1-4-1. LED Indicator Status
Protective Circuit Output short protection, Power supply reverse polarity protection
Insulation Resistance 20 M or higher (500 VDC megger)
Dielectric Strength 1,000 VAC, 50/60 Hz (1 min)
Functional
Mutual Interference Prevention
(Scan Code)
This function prevents mutual interference in up to
two F3SG-RA systems.
-
4-1-4. Mutual Interference Prevention
Cascade Connection
Number of cascaded segments: 3 max.
Total number of beams: 255 max.
Cable length between sensors: 10 m max.
-
Test Function
Self-test (at power-on, and during operation)
External test (light emission stop function by test
input)
Self-test (at power-on, and during operation)
Safety-Related Functions
Interlock
External device monitoring (EDM)
Pre-reset
Fixed blanking/Floating blanking
Reduced resolution
Muting/Override
Scan code selection
PNP/NPN selection
Response time adjustment
Chapter 2 System Operation and Functions
Chapter 3 Setting with DIP Switch
-
Environmental
Ambient
Temperature
Operating -10 to 55°C (14 to 131°F) (non-icing)
Storage -25 to 70°C (-13 to 158°F)
Ambient
Humidity
Operating 35% to 85% (non-condensing)
Storage 35% to 95%
Ambient Illuminance
Incandescent lamp: 3,000 Ix max. on receiver surface
Sunlight: 10,000 Ix max. on receiver surface
Degree of Protection
(IEC 60529)
IP65 and IP67
Vibration Resistance
(IEC 61496-1)
10 to 55 Hz, Multiple amplitude of 0.7 mm, 20 sweeps for all 3 axes
Shock Resistance
(IEC 61496-1)
100 m/s
2
, 1000 shocks for all 3 axes
F3SG-4RA-14
F3SG-2RA-14
F3SG-4RA-30
F3SG-2RA-30
F3SG-4RE14
F3SG-2RE14
F3SG-4RE30
F3SG-2RE30

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
