13
F3SG-R
User’s Manual
Chapter1 Ratings/Specifications
Overview and Specifications
E
Pollution Degree
(IEC 60664-1)
Pollution Degree 3
Connections
Power cable
Type of
Connection
M12 connectors: 5-pin emitter and 8-pin receiver,
IP67 rated when mated,
Cables prewired to the sensors
M12 connectors: 4-pin, IP67 rated when mated,
Cables prewired to the sensors
Number of
Wires
Emitter: 5, Receiver: 8
Emitter: 4, Receiver: 4
Cable
Length
0.3 m
Cable
Diameter
6 mm
Minimum
Bending
Radius
R5 mm
Cascading cable
Type of
Connection
M12 connectors: 5-pin emitter and 8-pin receiver,
IP67 rated when mated
-
Number of
Wires
Emitter: 5, Receiver: 8
Cable
Length
0.2 m
Cable
Diameter
6 mm
Minimum
Bending
Radius
R5 mm
Extension cable
- Single-ended
cable
- Double-ended
cable
Type of
Connection
M12 connectors: 5-pin emitter and 8-pin receiver,
IP67 rated when mated
Use the XS5-D42 series cables.
Number of
Wires
Emitter: 5, Receiver: 8
Cable
Length
Refer to 4-5-3-1. Single-Ended Cable and
4-5-3-2. Double-Ended Cable for cable
lengths and twisted pair wires.
Cable
Diameter
6.6 mm
Minimum
Bending
Radius
R36 mm
Extension of Power Cable 100 m max.(Emitter/Receiver)
Material
Material
Housing: Aluminum
Cap: PBT
Front window: PMMA
Cable: Oil resistant PVC
Mounting Bracket: ZDC2
FE plate: SUS
Weight (packaged) Refer to 1-6. List of Models
Included Accessories Safety Precautions, Quick Installation Manual, Standard Fixed Bracket*1, Troubleshooting Guide
Sticker, Warning Zone Label *2
*1. The quantity of Standard Fixed Brackets included varies depending on the protective height.
[F3SG-RA-14]/F3SG-RE14]
- Protective height of 0160 to 1200: 2 sets
- Protective height of 1280 to 2080: 3 sets
[F3SG-RA-30]/F3SG-RE30]
- Protective height of 0190 to 1230: 2 sets
- Protective height of 1310 to 2270: 3 sets
- Protective height of 2350 to 2510: 4 sets
*2. Included in the F3SG-RA series.
F3SG-4RA-14
F3SG-2RA-14
F3SG-4RA-30
F3SG-2RA-30
F3SG-4RE14
F3SG-2RE14
F3SG-4RE30
F3SG-2RE30
To Next Page
