Omron F3SG series User Manual

40
Chapter2 External Device Monitoring (EDM)
F3SG-R
User’s Manual
System Operation and Functions
Make sure the Position 8 of the DIP Switch is set to Configuration Tool Enabled to activate the settings by the
Configuration Tool.
After you make any change to the setting, verify that the F3SG-RA goes to the Lockout state when the F3SG-RA is wired
in such a way that the specified voltage is applied directly to the RESET input of the receiver without the N.C. contact of
an external device.
Refer to Safety Light Curtain Configuration Tool for Model F3SG (SD Manager 2) User’s Manual for more
information on setting this function by the Configuration Tool.

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
