Custom Dialogs
100
Vision System FH/FZ5 Series
User’s Manual (Z340)
• Binary Dialog Box Setting Region
Scattering R's data No.
−1 to 999999999
[−1]
Specifies the R’s data number for the difference in the unit to
use for color extraction.
Scattering G's data No.
−1 to 999999999
[−1]
Specifies the G’s data number for the difference in the unit to
use for color extraction.
Scattering B's data No.
−1 to 999999999
[−1]
Specifies the B’s data number for the difference in the unit to
use for color extraction.
[Data reference] button ---
You can select the data number directly to enter it, or you
can enter it with the [Data reference] button.
Click the [Data reference] button to select the target data in
the [Data reference] dialog box.
Parameter Set value [Factory default] Description
Binary upper's data No.
−1 to 999999999
[−1]
Specifies the upper data number for the unit to use for binary
filtering.
Binary lower's data No.
−1 to 999999999
[−1]
Specifies the lower data number for the unit to use for binary
filtering.
Binary reverse's data
No.
−1 to 999999999
[−1]
Specifies the reverse data number for the unit to use for
binary filtering.
[Data reference] button ---
You can select the data number directly to enter it, or you
can enter it with the [Data reference] button.
Click the [Data reference] button to select the target data in
the [Data reference] dialog box.
Parameter Set value [Factory default] Description
