Before Operation
Vision System FH/FZ5 Series
User’s Manual (Z340)
Windows
Types of Windows
There are 9 windows (with layout numbers 0 to 8) that you can use to set and operate an FH/FZ5.
Layout Application
Layout 0
Layout 0 is the adjustment window by default.
(Reference: Main Window (Layout 0): Adjustment Window (Default) (p.68))
Layout 1
Layout 1 is a run window by default.
(Reference: Main Window (Layout 1): Run Window (Default) (p.69))
Layout 2 to layout 8
Layouts 2 to 8 are for user-defined purposes and are created as they are needed. (Reference:
Arranging the Window Display (p.92))
For example, if more than one line is being controlled, you can set and use a separate window
for each line.
(Reference: Multi-line Random-trigger Mode (p.273))
If necessary, you can change layout 0 and layout 1 from the default adjustment window and run window and use them for
other purposes.
If the operation mode is set to Multi-line Random-trigger Mode, you must create a layout for each line. (Reference: Multi-
line Random-trigger Mode (p.273))
