Flow of Application
26
Vision System FH/FZ5 Series
User’s Manual (Z340)
↓
Scene Editing
In the Main Window (layout 0), edit the measurement flow.
• Register processing items.
• Set the properties for each processing item.
Reference: Setting Scenes
(Measurement Flows) (p.47)
↓
Click the [Data save] button.
Reference: Saving
Settings before Turning OFF
the Power and Restarting
(p.43)
Reference: Loading
Settings Data from the
Controller RAM Disk or an
External Memory Device to
the Sensor Controller (p.261)
↓
Testing
Execute test measurements.
(In the Main Window (layout 0), click the [Measure] button.)
Reference: Performing
Test Measurement/Starting
Operation (p.67)
↓
Adjust the parameters for each processing item.
Vision System FH/FZ5 Series
Processing Item Function
Reference Manual (Cat. No.
Z341)
↓
Click the [Data save] button.
Reference: Saving
Settings before Turning OFF
the Power and Restarting
(p.43)
Reference: Loading
Settings Data from the
Controller RAM Disk or an
External Memory Device to
the Sensor Controller (p.261)
↓
Measuring
(Operation)
In the Main Window (layout 0), click the [Switch layout] button, and then
select [Main Window (Layout 1)].
Reference: Performing
Test Measurement/Starting
Operation (p.67)
↓
In the Main Window (layout 1), check the communications with the PLC.
Vision System FH/FZ5 Series
User's Manual for
Communications
Settings (Cat. No. Z342)
↓
In the Main Window (layout 1), execute commands from the PLC, such as
measurement trigger commands.
Vision System FH/FZ5 Series
User's Manual for
Communications
Settings (Cat. No. Z342)
↓
Management and
Analysis
Save and analyze measurement data and images.
Reference: Useful
Functions for Operation
(p.109)
Reference: Using Tools
(p.131)
Procedure Description Reference
