Arranging Windows
91
3
Performing Test Measurement/Starting Operation
Vision System FH/FZ5 Series
User’s Manual (Z340)
Troubleshooting
Symptom Setting Correction
The RUN signal is not
output.
Layout setup
Select [Layout setup] from the [Window] menu and select the [RUN signal
output] check box for the layout to be used.
The layout of the Image
Display Area cannot be
changed.
---
Click the button in the upper right corner of the Image Display Area if the
Layout Modification Pane is not visible in the Main Window.
Cannot create a backup of
the layout settings.
---
The layout data is included in the system data and saved in the Sensor
Controller when you click [Data save].
To save or load the settings to or from a file, click [Save to file] or [Load from
file] to save or load the system data and scene group 0 data or the system
settings data.
An image of a window object
remains in the Main Window
when modifying the layout.
Layout
modification
When you finish modifying the layout, the display will be updated and
window objects will be displayed correctly.
Cannot output measurement
results after the layout is
changed
Layout setup
When "Output" is set to OFF in the layout setup of the layout that is used,
measurement results are not output after startup or after the layout is
changed.
Even when the "Output" option is selected in the Measurement Pane of the
Main Window, the "Output" setting in the layout setup is applied when the
layout is changed.
Before executing measurement, set "Output" to ON in the layout setup of
the layout that is used.
